• Simple Fabric Input Control
  Fabric input controlled from motor driven cradle for tension free un winding


• End Roll Automatic Stop Sensor - for next roll joining
  This will allow for efficient and continuous inspection from roll to roll


• Full Width Fabric Inspection- with variable angle inspection screen
  Fabric can be examined with different viewing and lighting options inclusive of Ultra Violet Lighting. Forward/Reverse/Stop Push Button control mounted near inspection table.


• Consistent Roll Output -with Twin Re-wind Rubberized Rolls
  Processed rolls are rewound with minimum amount of tension and are consistent from roll to roll. Fabric is wound on positively driven rubberized rollers by surface contact.


• Automatic Tension Control
  Electronic tension control device varies the fabric speed to maintain the desired tension


• Versatile fabric input and output options- Synchronized with other Production Operations
  Systems are available for different fabric input and output presentations, roll to roll, continuous fabric input, face in/face out etc., for synchronize with other operations.


• Data Collection and analysis System- with Fault logging
  100 % Fabric inspection with sample push buttons for accurate fault logging, allowing fabric roll analysis and print out. Unit comes with a RS232 connector, so that the fabric fault data can be transferred in to your quality control department computer, at the end of the shift. Data in production per shift with date and time stamp is also provided

• Minimum Maintenance
  Machine is designed for practically maintenance free performance. Routine maintenance is not necessary since all drive systems are run Flat belt, Timing belts and self aligning, self lubricating sealed bearings.
